Description
This is a 1-3/16 in. concave bronze ball bearing roller assembly that installs into a 7/16 in. deep by 2-15/16 in. long mortised pocket on each end of the solid wood closet door bottom rail. The roller assembly is held in place by two 3/4 in. long screws. The bracket is stamped steel with a 1-3/16 in. brass concave roller installed. Rides on a metal track installed onto the floor. Used by a variety of manufacturers of solid wood closet doors.
- Stamped steel bracket
- 2-1/2 in. mounting holes
- 1-3/16 in. concave bronze ball bearing roller
- Fits into a 7/16 in deep by 2-15/16 in long mortised pocket in the bottom of wood closet doors
- Rides on a metal track installed on the floor
- Used by a variety of manufacturers of solid wood closet doors
- For further dimensional information, please see the line drawing
| SKU | 106808 | UPC | 049793971920 |
| Weight | 0.11 lbs | Package Width | 3.75 in |
| Package Length | 0.65 in | Package Height | 5.35 in |
| Model Number | N 7192 | Brand | Prime Line |
| Manufacturer Name | PRIME LINE PRODUCTS |
