Description
9.5hp KohlerCommand ProEngine2:1 Gear Reduction with Clutch22mm x 52.5mm output shaftRecoil and electric start with 10amp alternatorOHV, dual ball bearing PTO, cast iron cylinder liner,Recoil start, low oil device.Universal replacement type engine3year warranty.Model CH395-3038.65lbs
Engine Type:
4-cycle, gasoline, OHV, cast iron cylinder liners, aluminum block
Model |
Command PRO CH395 |
| Max Power @3600 RPM hp (kW) | 9.5 (7.1) |
| Displacement cu in (cc) | 16.9 (277) |
| Bore in (mm) | 3.1 (78) |
| Stroke in (mm) | 2.3 (58) |
| Peak Torque @ Maximum lbs ft (Nm) | 13.2 (17.8) |
| Compression Ratio | 8.2:1 |
| Dry Weight lbs (kg) | 61.5 (27.8) |
| Oil Capacity U.S. quarts (L) | 1.2 (1.1) |
| Lubrication | Splash |
| Dimensions L x W x H in | 15.9 x 16.8 x 16.7 |
Kilowatt (kW) and horsepower (HP) specifications for Kohler general purpose engines are calculated pursuant to the Society of Automotive Engineers (SAE) J1940 for horsepower ratings – calculated with the air cleaner and muffler removed, per the SAE standard. Actual engine horsepower is lower and affected by, but not limited to, accessories (air cleaner, exhaust, charging, cooling, fuel pump, etc.), application, engine speed and ambient operating conditions (temperature, humidity and altitude). The reason for this standard is to provide consistent measurement to customers who may want to control the intake and exhaust features of the engine. It is important to note that the power output of all Kohler engines is always as advertised. For more information, contact Kohler Co. Engine Engineering Department. Kohler Co. reserves the right to change product specifications,designs and standard equipment without notice and without incurring obligation.
Standard Features:
Overhead Valve Design
Electronic Ignition
Quad-Clean
TM 4-Stage All-Season Heavy Duty Cyclonic Air Cleaner
Dual Oil Fill Locations and Oil Drains
Cast Iron Cylinder Liner
7.4 L Metal Tank w/Strainer
Fuel Shut-off Valve
Stellite
Exhaust Valve
Engine Mounted Throttle and Choke Controls, Remote Throttle Ready
Oil Sentry
TM Switch Installed (No Light)
Dual Ball Bearings, PTO and Flywheel
Balance Shaft
Metal Blower Housing
Indexable Recoil Starter
Crankshaft – 1.0″ (25.4 mm) Diameter x 3.49″ (88.61 mm) PTO Length,
Tapped 7/16-20 UNF
PTO Face – 6.5″ (165.1 mm) Diameter Bolt Circle (4 Holes) 3/8-16 UNC x 0.71″ (18 mm) Deep
and 5″ (127 mm) Diameter Bolt Circle (4 Holes) 5/16-24 UNF x 0.71″ (18 mm) Deep
Large Capacity Muffler w/Heat Shield and Spark Arrestor
Owner’s Manual (Multi-language for Europe or Quad-Language for rest of the world)
EPA Phase 2 and EU Stage 2 Emission Compliance
Color – Black with Cast Aluminum
