Description
Fluke 305 Clamp Meter Full Specifications
Electrical Measurement
-
AC current: Up to999.9A, accuracy 2% +5 digits
-
AC voltage: 400V / 600V, accuracy 1.5% +5 digits
-
DC voltage: 400V / 600V, accuracy 1.5% +5 digits
-
Resistance: Up to4000, accuracy 1% +5 digits
-
Continuity: Audible alert 70
Display & Functionality
-
Backlit LCD display for visibility in dim conditions
-
Data Hold function to freeze readings
-
Screen refresh rate: updates at over 2 readings per second
Physical & Safety Specs
-
Jaw opening size: 30mm
-
Dimensions: ~20858.528mm
-
Weight: Lightweight and ergonomic for easy carrying
-
Safety categories: CATIII 600V / CATIV 300V
Environment & Power
-
Operating temperature range: 0C to 40C
-
Typical operating humidity: Non-condensing (e.g. 90% RH at 1030C)
-
Power source: 2 AA batteries (included)
Included Accessories
-
Test leads: TL75 style (hardpoint probes, rightangle banana plugs)
-
Other contents: Batteries, user manual
Quick Summary Table
| Feature | Specification |
|---|---|
| Maximum AC current | 999.9 A (2% +5 digits) |
| AC/DC Voltage Ranges | 400 / 600 V (1.5% +5 digits) |
| Resistance Range | Up to 4k (1% +5 digits) |
| Continuity Threshold | 70 (audible alert) |
| Display | Backlit LCD with data hold |
| Jaw Opening | 30 mm |
| Size (HxWxD) | ~20858.528mm |
| Power | 2 AA batteries |
| CAT Safety Ratings | CAT III 600 V / CAT IV 300 V |
| Operating Temperature | 0C to 40C |
| Test Leads | TL75 type included |
