Description
Blue-White F-30200P Flow Meter, 2″ Pipe (20120 GPM)
2″ Blue-White F-300 flow meter (F-30200P), 20120 GPM. One-piece acrylic body, pitot-tube design, NSF/ANSI 50 listed. Horizontal model. Includes SS clamps.
Features
- 20120 GPM range on 2″ pipe with dual GPM/LPM scale.
- Pitot-tube design installs on existing PVC or copper lines.
- One-piece, machined acrylic body; includes stainless-steel clamps and gasket.
The F-30200P is the horizontal F-300 model for 2″ lines. It clamps onto a straight run, reads clearly in sunlight, and is NSF/ANSI 50 listed for pool and spa use. No separate mounting screws are neededjust position, clamp, and verify flow.
Pro Tip
Installing on a vertical run? Use the D-300 (downflow) or U-300 (upflow) version to maintain accuracy.
Related Parts
Installation Tips
Follow Blue-Whites straight-run guidance. Verify pipe schedule and orientation. For F-300 (horizontal) units the max working pressure is 50 PSI at 70F; U/D vertical versions are rated to 75 PSI. Always depressurize the line before service.
